Airtac F-M-F Floating Joint Assembly F-M6X100F
AirTAC F-M-F Floating Joint Assembly F-M6X100F Technical Specifications
- Full model designation: F-M6X100F
- Thread specification: M6×1.0 metric thread
- Float compensation: ±2.5° angular misalignment
- Axial float range: ±1.2mm
- Material composition:
- Body: Anodized aluminum alloy 6063-T5
- Ball joint: Chrome-plated carbon steel
- Seals: NBR (Nitrile) rubber
- Max torque resistance: 3.5 N·m
- Installation method: Through-hole mounting with M6 hex nut
- Temperature tolerance: -20℃ to 80℃
- Surface treatment: Black anodized (body), Cr³+ plating (steel components)
- Compatible tube OD: 6mm (1/4") pneumatic tubing
- Pressure rating: 0.05-1.0 MPa
- Weight: 82g ±3g
- Dimensions: 100mm(L) × 24mm(W) × 24mm(H)
Precision floating joint assembly designed for vibration absorption and misalignment compensation in pneumatic systems. Features dual-axis compensation with maintenance-free ball joint structure, ideal for applications requiring smooth articulation under continuous motion. Includes pre-assembled M6 male threads with anti-vibration lock nut.
- Industrial robot end-effector connections
- Vibration-prone conveyor line actuators
- Multi-axis pneumatic tool positioning systems
- Packaging machinery with reciprocating motions
- Semiconductor handling equipment requiring precise alignment
Installation guidance:
Apply 2-3Nm torque during installation. For optimal performance,
maintain minimum 15mm clearance around joint body and perform
monthly lubrication of ball joint with silicone-based grease.
| Property | Property Value |
|---|---|
| sku | F-M6X100F |
| Thread Pitch | <1.0mm> |
| Thread Specification | <6mm> |
