Airtac F-M-F Floating Joint Assembly F-M8X125F
AirTAC F-M-F Floating Joint Assembly F-M8X125F Technical Details
- Full model designation: F-M8X125F
- Type: Double-acting floating joint with integrated rod ends
- Thread specification: M8×1.25 male thread (ISO metric standard)
- Effective stroke: 125mm (±62.5mm compensation range)
- Max axial load capacity: 180N (dynamic), 350N (static)
- Max radial load capacity: 90N (dynamic), 180N (static)
- Rotation angle: ±5° angular misalignment compensation
- Body material: Anodized aluminum alloy (A6061-T6)
- Rod material: Chromium-molybdenum steel (SCM435)
- Seal type: Dual NBR O-rings + PU dust wiper
- Temperature tolerance: -20℃ to 80℃ (continuous operation)
- Surface treatment: Black electrophoretic coating (7-12μm)
- Weight: 350g ±5% (including all hardware)
- Dimensions: 156mm(L) × 34mm(W) × 34mm(H) (fully extended)
- Included components: 2x lock nuts (M8), 4x anti-vibration washers
Precision-aligned floating connector designed for pneumatic and low-speed mechanical systems requiring axial/radial misalignment absorption. Features triple-bearing design (radial ball bearing + angular contact bearing + thrust washer) for smooth multi-directional movement. Rated for 500,000 cycles at max load.
- Industrial robot end-effector compensation in pick-and-place systems
- Vibration isolation for CNC machine tool coolant nozzles
- Conveyor belt tension adjustment mechanisms
- Semiconductor wafer handling equipment
- Packaging machine rotary-to-linear motion conversion
Mounting protocol:
Apply 2.5-3.5N·m torque during installation. Lubricate bearing surfaces with ISO VG32-grade oil before initial use.
Avoid simultaneous axial and radial overload beyond 70% of rated capacity.
| Property | Property Value |
|---|---|
| sku | F-M8X125F |
| Thread Pitch | 1.25mm |
| Thread Specification | <8mm> |
