Airtac F-M-U Rod End Joint Assembly Kit F-M4X070U
AirTAC F-M-U Series Rod End Bearing Kit F-M4X070U Technical Details
- Model: F-M4X070U
- Type: Metric male-threaded rod end bearing assembly
- Thread specification: M4×0.7 (external)
- Rod diameter: 7mm ±0.2mm
- Total length: 70mm (body + threaded portion)
- Swivel angle: ±15° free rotation
- Max static load: 980N axial / 490N radial
- Max dynamic load: 490N axial / 245N radial
- Material: Carbon steel body with zinc-nickel plating
- Bearing type: Maintenance-free polymer plain bearing
- Temperature range: -20℃ to +80℃
- Weight: 52g ±3g
- Dimensions: 70mm(L) × 14mm(W) × 14mm(H)
- Package content: 50pcs/PE bag with anti-corrosion coating
Precision-aligned rod end bearing kit featuring zero-clearance ball joint design for vibration dampening in linear motion systems. The zinc-nickel coating provides 500hr salt spray resistance, while the PTFE-impregnated bearing ensures smooth articulation without lubrication. Includes integrated locknut for secure mounting.
- Pneumatic cylinder linkage in pick-and-place robots
- Conveyor belt tension adjustment mechanisms
- 3D printer extruder head positioning systems
- Packaging machine cam follower attachments
- Semiconductor equipment vibration isolation mounts
Installation protocol:
Apply 2.5-3.0N·m torque during installation using thread-locking compound.
Avoid axial sideload exceeding 30% of joint diameter. Perform rotational
alignment check every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | F-M4X070U |
| Thread Pitch | <0.7mm> |
| Thread Specification | M4 |
