Airtac F-M-U Rod End Joint Assembly Kit F-M5X080U
$6.94
Regular price
$14.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-M5X080U
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Category:** Cylinder Rod Eye Joint
**Brand:** Airtac
**Series:** F-M-U
**Product Description:**
Airtac's F-M-U Series Cylinder Rod Eye Joints are precision-engineered for seamless integration with pneumatic cylinders, ensuring reliable alignment and load distribution in automation systems. Featuring hardened steel construction, corrosion-resistant coatings, and standardized ISO/VDMA mounting interfaces, these eye joints deliver exceptional durability and vibration resistance. Designed for high-cycle applications, they support smooth angular compensation (±3°) while maintaining rigid axial stability. The pre-lubricated spherical bearing design minimizes friction, extending service life in demanding industrial environments. Compatible with ISO 6432 and ISO 15552 cylinder standards.
Installation guidance:
Apply thread locker (Loctite 243 recommended) on male threads before assembly.
Use calibrated torque wrench - over-tightening may deform bearing race.
Align movement axis within ±3° of bearing centerline for optimal service life.
AirTAC F-M-U Series F-M5X080U Rod End Bearing (Fish Eye Joint) Complete Kit
- Model: F-M5X080U
- Type: Female threaded rod end bearing with lock nut
- Thread size: M5×0.8 (internal)
- Bore diameter: 8mm (±0.01mm tolerance)
- Swivel angle: ±15° max. deflection
- Load capacity: 0.8kN static / 0.4kN dynamic
- Material: Carbon steel body + PTFE-lined spherical bearing
- Surface treatment: Zinc-nickel plating (8-12μm)
- Operating temperature: -30℃ to +120℃
- Torque range: 1.5-2.0N·m (recommended installation torque)
- Weight: 28g ±1g
- Dimensions: 32mm(Total L) × 20mm(Flange W) × 16mm(H)
- Included components: Rod end bearing ×1, M5 lock nut ×1, Dust cover ×2
Precision-aligned rod end bearing with integrated sealing for smooth articulation in confined spaces. Features maintenance-free PTFE/steel composite bearing surface and corrosion-resistant plating. Pre-lubricated with high-temperature grease (Molykote EM-30L equivalent).
Typical Applications:
- Pneumatic cylinder linkage systems
- 3D printer axis tensioning mechanisms
- CNC machine tool limit switch actuators
- Robotic arm wrist joint assemblies
- Automotive throttle linkage adjustments
Installation guidance:
Apply thread locker (Loctite 243 recommended) on male threads before assembly.
Use calibrated torque wrench - over-tightening may deform bearing race.
Align movement axis within ±3° of bearing centerline for optimal service life.
| Property | Property Value |
|---|---|
| sku | F-M5X080U |
| Thread Pitch | <0.8 mm> |
| Thread Specification | M5 |
