Airtac F-MF-I Adapter Assembly Kit F-MF20I
Brand: AIRTAC
Series: F-MF-I
Category: Pneumatic Automation Components Professional Description: The AIRTAC F-MF-I Series represents precision-engineered Type I pneumatic cylinder connectors designed for industrial automation systems. This complete fitting solution features standardized thread specifications and optimized flow path architecture, ensuring leak-free connections in pneumatic control circuits. The kit includes factory-assembled components with corrosion-resistant brass construction and BSPP/BSPT/NPT thread compatibility. Engineered for 0-1.0 MPa operating pressure range, these fittings demonstrate exceptional vibration resistance and maintain consistent performance across -5°C to 60°C operational temperatures. Ideal for pneumatic cylinder port connections in automated machinery, the series complies with ISO 6432 standards while incorporating AIRTAC's proprietary sealing technology for enhanced durability in high-cycle applications.
AirTAC F-MF-I Fitting Kit F-MF20I Technical Specifications
- Model: F-MF20I (Pack of 10 pcs)
- Type: Metric push-to-connect straight thread fitting
- Thread standard: M5×0.8 male threads
- Tube compatibility: 4mm OD polyurethane/nylon tubing
- Body material: Nickel-plated brass (CuZn39Pb3)
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Operating pressure: 0.05-1.0 MPa
- Temperature range:
- Operation: -20℃ to 80℃
- Storage: -30℃ to 100℃
- Vibration resistance: ≤5Hz (ISO 4414)
- Weight: 3.2g per piece (±0.15g)
- Dimensions (single unit):
- Length: 18.5mm
- Width: 10mm (hex size)
- Height: 10mm
- Package dimensions (10 pcs):
- Length: 120mm
- Width: 75mm
- Height: 25mm
Pre-assembled metric pneumatic fitting kit featuring tool-free installation and positive-lock mechanism. The corrosion-resistant nickel plating ensures durability in humid environments, while the 60° cone seat design prevents tube slippage under pressure fluctuations. Includes integrated flow control with 1.5mm orifice for regulated airflow.
- Compact pneumatic circuit connections in robotic arms
- Modular assembly systems requiring quick tube changes
- Medical device gas line interfaces
- Semiconductor manufacturing equipment
- Packaging machine sensor air supply lines
Installation guide:
Insert tube straight into port until "click" is heard. For optimal performance:
- Cut tube ends square (90°±2° tolerance)
- Maximum axial pull force: 25N
- Releases with 2.5mm collar pull (use release tool for tight spaces)
Do NOT use with:
- Plasticizer-containing tubing (causes seal swelling)
- Pulsation frequencies above 5Hz
- Petroleum-based lubricants (use silicone-based only)
| Property | Property Value |
|---|---|
| sku | F-MF20I |
