Airtac F-SC-H Sensor Mounting Bracket Assembly F-SC125SH
AirTAC F-SC-H Series Sensor Bracket Kit F-SC125SH Specifications
- Model: F-SC125SH
- Type: Universal proximity sensor mounting bracket kit
- Material: Aluminum alloy (anodized black finish)
- Compatible Sensors: M12/M18 cylindrical sensors
- Mounting Options: DIN rail (35mm) or direct bolt mounting
- Clamping Range: 4-12mm diameter sensors
- Weight: 82g ±2g
- Dimensions: 50mm(L) × 40mm(W) × 25mm(H)
- Surface Hardness: HV 400-450
- Temperature Range: -25℃ to 85℃
- Corrosion Resistance: 96hr salt spray test passed
- Included Components: Main bracket, 2 adjustable clamps, M4x10 screws (4pcs), T-slot nuts (2pcs)
Precision-engineered sensor mounting solution featuring tool-less adjustment and dual-axis positioning capability. The hardened aluminum construction withstands industrial vibration while maintaining precise sensor alignment. Integrated cable management slots and 360° rotational flexibility enable clean installations in confined spaces.
- CNC machine tool position detection
- Automated packaging line sensor arrays
- AGV (Automated Guided Vehicle) proximity systems
- Robotic arm end-effector alignment
- Conveyor belt object detection stations
Installation note:
Apply 0.3-0.5Nm torque when tightening clamp screws. For dynamic environments,
use thread-locking adhesive on adjustment mechanisms. Regular cleaning of
T-slot channels recommended in high-particulate environments.
| Property | Property Value |
|---|---|
| sku | F-SC125SH |
