Airtac F-SC-H Sensor Mounting Bracket Assembly F-SC160SH
AirTAC F-SC-H Series Sensor Bracket Kit F-SC160SH Technical Details
- Model: F-SC160SH (Complete Kit)
- Material: Aluminum alloy 6063-T5 with anodized surface treatment
- Mounting Type: Horizontal/Vertical dual-orientation design
- Compatible Sensors: M8/M12/M18 cylindrical sensors (Ø12-18mm adjustment range)
- Clamping Force: 8-12N·m (adjustable via integrated hex socket)
- Rail Compatibility: 35mm DIN rail (EN 50022 standard)
- Weight: 250g ±5% (including all mounting accessories)
- Dimensions: 160mm(L) × 40mm(W) × 25mm(H)
- Temperature Range: -40℃ to +85℃ (anti-corrosion coating included)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude (IEC 60068-2-6 compliant)
- IP Rating: IP67 when properly installed
- Accessories Included: 4×M5 stainless steel bolts, 2×T-slot nuts, 1×adjustment tool
Heavy-duty modular sensor mounting solution featuring 360° rotational adjustment and tool-free position locking. The hardened aluminum construction withstands mechanical stress in high-cycle applications, while the conductive coating prevents electrostatic discharge (ESD) in sensitive environments. Integrated cable management channels accommodate Ø4-8mm sensor cables.
- Position detection in automated assembly lines
- Robotic arm end-effector sensor mounting
- Packaging machine photoelectric sensor fixation
- Material handling system proximity switch installation
- CNC machine tool limit switch configuration
Installation note:
For optimal stability, tighten center bolts in cross pattern sequence.
Apply 0.5N·m torque for plastic-bodied sensors or 1.2N·m for metal sensors.
Use included silicone gasket when operating in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | F-SC160SH |
