Airtac F-SC-H Sensor Mounting Bracket Assembly F-SC250SH
AirTAC F-SC-H Sensor Mounting Bracket Kit F-SC250SH Technical Details
- Model: F-SC250SH (Complete Kit)
- Material: Anodized aluminum alloy (AL6063-T5)
- Compatible sensor types: Cylindrical proximity sensors (Φ25mm body)
- Mounting method: Dual M5 threaded holes + T-slot rail compatible
- Adjustment range: ±15° vertical tilt adjustment
- Clamping force: 18N·m max (via hex socket screws)
- Surface hardness: HV400-450
- Temperature resistance: -40℃ to +120℃
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP67 (sealed with silicone gasket)
- Weight: 320g ±5% (including all hardware)
- Dimensions: 250mm(L) × 42mm(W) × 42mm(H)
- Included components: Main bracket, 4x M5x12 stainless screws, 2x positioning shims (0.5mm/1.0mm), anti-vibration washer set
Heavy-duty sensor mounting solution with micro-adjustment capability, featuring dual-axis alignment slots for precise sensor positioning. The thermal-stable design maintains dimensional accuracy in fluctuating temperatures, while the conductive anodized coating prevents EMI interference.
- Palletizing robot end-effector position feedback
- CNC machine tool limit detection systems
- Automated warehouse shuttle alignment sensors
- Food processing conveyor belt object detection
- Lithium battery production line safety interlocks
Installation guidance:
Apply 2.5-3N·m torque during screw tightening. Use included nylon washers when mounting on vibrating equipment.
For vertical installations, orient drain slot downward.
| Property | Property Value |
|---|---|
| sku | F-SC250SH |
