Airtac F-SC-H Sensor Mounting Bracket Assembly F-SC63H
$3.68
Regular price
$11.18
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SC63H
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AirTAC
Series: F-SC-H Sensor Mounting Bracket Complete Assembly Kit
Professional-grade sensor mounting solution designed for precise alignment and secure fixation of inductive/proximity sensors on pneumatic cylinders. Features corrosion-resistant anodized aluminum construction with standardized T-slot design for universal compatibility. Includes pre-assembled mounting components, adjustment screws, and fasteners to streamline sensor installation. Engineered to maintain stable sensing performance under high vibration and dynamic industrial environments.
Mounting guidance:
Apply 0.5-0.7N·m torque during sensor installation. Use shim washers
(not included) when mounting on curved surfaces. Clean T-slot rails
with IPA before assembly to prevent particulate interference.
AirTAC F-SC-H Series Sensor Bracket Kit F-SC63H Technical Details
- Model: F-SC63H (Complete Kit)
- Material: Aluminum alloy ADC12 with black anodized finish
- Compatible Sensors: M8/M12 cylindrical inductive/capacitive sensors
- Mounting Type: T-slot rail mounting (8mm/15mm rail compatible)
- Thread Specifications: M4×0.7 mounting threads (4 positions)
- Surface Hardness: HV 400±20 (anodized layer)
- Torque Specifications: Max 1.2N·m for sensor clamping
- Operating Temperature: -25℃ to +80℃ (no condensation)
- IP Rating: IP40 (protected against 1mm+ solids)
- Weight: 182g ±5g (including all hardware)
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H)
- Included Components: Bracket body, M4×16 hex socket screws (4pcs), T-nuts (2pcs), spring washers (4pcs)
Robust modular mounting solution designed for precise sensor alignment in automated systems. Features anti-vibration design with integrated cable management grooves (3mm depth) and 360° adjustable sensor positioning. Anodized surface resists industrial coolants and mild chemicals.
Typical Installation Scenarios:
- Position verification in linear guide systems
- Object detection on conveyor belt edges
- Pallet presence sensing in AS/RS warehouses
- End-of-stroke detection for pneumatic cylinders
- Tool position monitoring in CNC machine enclosures
Mounting guidance:
Apply 0.5-0.7N·m torque during sensor installation. Use shim washers
(not included) when mounting on curved surfaces. Clean T-slot rails
with IPA before assembly to prevent particulate interference.
| Property | Property Value |
|---|---|
| sku | F-SC63H |
