Airtac F-SC-H Sensor Mounting Bracket Assembly F-SC63SH
AirTAC F-SC-H Sensor Bracket Kit F-SC63SH Technical Details
- Model: F-SC63SH (Complete Assembly Kit)
- Compatible Sensor Series: SC-500/600/700 industrial proximity sensors
- Material: Anodized aluminum alloy AL6063-T5
- Mounting Type: M3 threaded through-hole installation
- Surface Treatment: Sandblasting + Matte black oxidation
- Horizontal Adjustment Range: ±3mm precision sliding
- Vertical Tilt Angle: ±5° adjustable
- Weight: 82g ±2g (including all fasteners)
- Dimensions: 63mm(L) × 20mm(W) × 15mm(H)
- Mounting Hole Pattern: 50mm × 10mm standardized spacing
- Operating Temperature: -25℃ to +85℃
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Protection Class: IP67 when paired with compatible sensors
- Included Components: Bracket body, M3×8 stainless screws (x4), anti-vibration shims (x2), alignment jig
Professional-grade sensor mounting solution featuring micro-adjustment capability for precise sensor alignment. The hardened anodized surface provides chemical resistance in harsh environments. Integrated cable management slots and universal mounting pattern compatible with DIN rail systems.
- Precision position detection in CNC machine tools
- Automated packaging line sensor arrays
- Robotic arm end-effector alignment systems
- High-vibration environments like injection molding machines
- Food processing equipment (FDA-compliant materials)
Installation Guidelines:
Use 0.4-0.6N·m torque for M3 fasteners. Apply thread-locking compound in high-vibration environments.
Clean mounting surface with isopropyl alcohol before installation. Maximum recommended sensor weight: 200g.
