Airtac F-SC-H Sensor Mounting Bracket Assembly F-SC80H
AirTAC F-SC-H Series Sensor Bracket Kit F-SC80H Technical Details
- Model: F-SC80H (Complete Assembly Kit)
- Material: Aluminum alloy 6063-T5 with black anodized finish
- Compatible sensor types: M8/M12 cylindrical sensors, rectangular sensors up to 22mm width
- Mounting hole spacing: 30mm ±0.2mm (horizontal adjustment range)
- Clamping force: 18-22N·m torque recommended
- Surface hardness: HV 400-450
- Weight: 285g ±5g (including all mounting hardware)
- Dimensions: 80mm(L) × 42mm(W) × 35mm(H)
- Operating temperature: -25℃ to +85℃ (no condensation)
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
- Included components: Main bracket, T-slot nuts (Qty 2), M6 hex socket screws (Qty 4), anti-vibration shims
Precision-machined positioning bracket with multi-axis adjustability, featuring tool-less sensor mounting and 4mm lateral fine-tuning capability. The hardened contact surfaces prevent wear from repeated adjustments, while the integrated cable management slots (5mm width) maintain clean installations. Compatible with DIN rail mounting or direct machine surface attachment.
- Photoelectric sensor alignment in automated packaging lines
- Proximity switch mounting on CNC machine tool carriages
- Position feedback device installation in robotic welding stations
- Safety interlock sensor positioning on assembly jigs
- Vibration monitoring equipment mounting in HVAC systems
Installation protocol:
Apply 0.1mm thick silicone damping pads (not included) between bracket and machine surface for high-vibration environments. Maximum recommended sensor payload: 500g. For angular adjustments, loosen center pivot bolt no more than 1/4 turn to maintain calibration accuracy.
| Property | Property Value |
|---|---|
| sku | F-SC80H |
