Airtac F-SC-H Sensor Mounting Bracket Assembly F-SC80SH
AirTAC F-SC80SH Sensor Mounting Bracket Complete Kit Specifications
- Model: F-SC80SH (F-SC-H Series)
- Type: Universal proximity sensor mounting solution
- Compatible sensor diameter: Ø8mm-Ø12mm
- Material: Aluminum alloy 6063-T5 with matte anodized finish
- Mounting options: Panel mount with M4×12mm hex socket screws
- Weight: 118g ±2g (including all hardware)
- Dimensions: 80mm(L) × 28mm(W) × 18mm(H)
- Surface hardness: HV 400-450
- Temperature resistance: -25℃ to +85℃
- Corrosion resistance: 96hr salt spray test passed
- Mounting torque: 0.8-1.2N·m (recommended)
- Package includes: Bracket body, 2x M4 stainless steel screws, 2x split washers, 2x flat washers
Precision-engineered mounting solution for industrial sensors featuring tool-less micro-adjustment capability (±3mm lateral movement). The zinc-nickel plated hardware provides exceptional corrosion resistance in humid environments. Precisely machined M4 threaded holes allow daisy-chaining multiple units.
- Position sensing in CNC machine tooling
- Automated packaging line quality control systems
- AGV (Automated Guided Vehicle) obstacle detection
- Pharmaceutical cleanroom equipment monitoring
- Robotic arm end-effector alignment
Installation protocol:
For optimal performance, ensure mounting surface flatness ≤0.1mm.
Apply thread-locking compound (medium strength) to prevent vibration-induced loosening.
Maximum recommended sensor cable diameter: Ø6mm.
| Property | Property Value |
|---|---|
| sku | F-SC80SH |
