Airtac F-SI-H Sensor Mounting Bracket Complete Kit F-SI100H
AirTAC F-SI-H Series Sensor Bracket Kit F-SI100H Technical Details
- Model: F-SI100H (Complete Kit)
- Compatible Sensors: M8/M12/M18 cylindrical inductive/capacitive sensors
- Material: Aluminum alloy 6063-T5 with black anodized finish
- Mounting Style: Dual-mode (M4 threaded holes + 35mm DIN rail compatible)
- Clamping Range: 8-20mm diameter sensors
- Weight: 118g ±2g (including mounting hardware)
- Dimensions: 72mm(L) × 42mm(W) × 25mm(H)
- Surface Hardness: HV 400-450
- Temperature Resistance: -25℃ to +85℃
- Vibration Resistance: 10-55Hz, 1.5mm double amplitude
- Corrosion Protection: 96hr salt spray test compliant
- Included Components: Bracket body, M4×12 stainless steel screws (Qty4), anti-vibration rubber pads (Qty2), DIN rail clip
Precision-machined universal sensor mount featuring tool-less adjustment and dual mounting capabilities. The hardened aluminum construction withstands mechanical stress in high-cycle applications, while the integrated cable management slots (3mm/5mm/8mm) maintain organized wiring. Compatible with ISO 4400 pneumatic standards.
- Position verification in robotic pick-and-place systems
- Conveyor belt object detection setups
- Pneumatic cylinder end-position sensing
- Packaging machine fill-level monitoring
- CNC machine tool safety interlock systems
Installation Best Practice:
For optimal stability, tighten mounting screws to 0.8-1.2N·m torque using crisscross pattern.
Apply silicone grease on rubber pads when used in environments exceeding 70% humidity.
| Property | Property Value |
|---|---|
| sku | F-SI100H |
