Airtac F-SI-H Sensor Mounting Bracket Complete Kit F-SI50H
AirTAC F-SI-H Series Sensor Bracket Kit F-SI50H Technical Details
- Model: F-SI50H (Complete Bracket Kit)
- Compatible Sensor Size: M12 to M30 cylindrical sensors
- Material: Anodized aluminum alloy (base) + Stainless steel clamp (SUS304)
- Mounting Type: Dual M5 threaded holes + Slot adjustment system
- Clamping Force: 15-20N·m (adjustable torque)
- Surface Finish: Sandblasted + Hard oxidation (HV400)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Temperature Tolerance: -40℃ to +120℃
- IP Rating: IP67 (sealed with high-grade silicone gasket)
- Weight: 228g ±5g (including all mounting hardware)
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H)
- Accessories Included: 3x M5×12 hex screws, 2x spring washers, anti-rotation plate
Heavy-duty universal sensor mounting solution with 360° rotational adjustment and shock-absorbing design. Features micron-level machining precision (Ra0.8) for stable positioning in high-vibration environments. The corrosion-resistant construction withstands coolant/oil exposure in industrial settings.
- Conveyor belt proximity sensor fixation
- Robotic arm end-effector position feedback devices
- CNC machine tool limit switch mounting
- AGV collision detection sensor brackets
- Food processing line photoelectric sensor installation
Installation protocol:
Apply 2-3Nm torque during initial tightening, then perform final torque adjustment after sensor alignment.
Use thread-locking adhesive on screws for permanent installations. Maintain 0.5mm gap between clamp and sensor housing for thermal expansion.
| Property | Property Value |
|---|---|
| sku | F-SI50H |
