Airtac F-SI-H Sensor Mounting Bracket Complete Kit F-SI63H
AirTAC F-SI-H Series Sensor Mounting Bracket Kit F-SI63H Technical Details
- Model: F-SI63H (Complete Bracket Kit)
- Compatible sensor size: Ø16mm cylindrical sensors
- Material: Anodized aluminum alloy 6063-T5
- Mounting type: Dual M4 threaded holes (pitch 30mm)
- Surface treatment: Hard anodized (25μm), MIL-A-8625 Type III compliant
- Clamping force: 3.5N·m max torque (via M5 hex socket screw)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Temperature range: -40℃ to +120℃
- IP rating: IP67 when installed with compatible sensor
- Weight: 82g ±2g (including all mounting hardware)
- Dimensions: 48mm(W) × 42mm(H) × 34mm(D)
- Kit includes: Mounting bracket, M5×16 stainless steel screw, spring washer, flat washer, hex key
Precision-machined sensor retention system featuring anti-rotation design with 3-point contact geometry. The thermal-stable construction maintains sensor alignment within ±0.1mm positional tolerance across temperature fluctuations. Integrated cable management slots accommodate Ø3-5mm sensor cables.
- Photoelectric sensor mounting in automated packaging lines
- Proximity switch installation on CNC machine tool carriages
- Position feedback sensor fixation for robotic end effectors
- Vibration-prone environments like injection molding machines
- High-cycle applications in automotive assembly jigs
Installation protocol:
Apply 0.3-0.5N·m pre-torque during sensor alignment, then final tighten to 3N·m.
Use thread-locking compound (medium strength) for permanent installations.
Compatible with ISO 9409-1-50-4-M5 mounting patterns.
