Airtac F-SI-H Sensor Mounting Bracket Complete Kit F-SI80H
AirTAC F-SI-H Sensor Mounting Bracket Kit F-SI80H Technical Details
- Model: F-SI80H (Complete Kit)
- Series: Heavy-duty H-type industrial sensor mount
- Material: Anodized aluminum alloy (black finish)
- Compatible Sensors: NPN/PNP inductive/capacitive Ø18mm cylindrical
- Mounting: M8×1.25 threaded rod or 8mm T-slot
- Adjustment Range: ±15° tilt, 360° rotation
- Clamping Force: 15N·m max torque
- Weight: 285g ±5g (including all hardware)
- Dimensions: 98mm(L) × 42mm(W) × 34mm(H)
- Temperature Resistance: -25℃ to +85℃
- Surface Hardness: HV 400-450
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- IP Rating: IP67 (when properly installed)
- Included Components: Main bracket, M5×12 hex screws (x4), M8 spring washer (x1), alignment shims (x2)
Robust modular mounting solution for precision sensor alignment in harsh industrial environments. Features triple-axis adjustability with locking hex screws and anti-vibration rubber inserts. The hardened anodized surface resists coolant splash and metal chips. Compatible with AS-Interface and IO-Link sensor models.
- Position verification in robotic gripper mechanisms
- Pallet detection on automated conveyor lines
- Tool presence monitoring on CNC machining centers
- Overhead crane limit switching systems
- Packaging machine fill-level sensing
Installation protocol:
Apply 0.5-0.8N·m torque during final tightening using calibrated tool.
Use included stainless steel shims when mounting on curved surfaces (>R50mm).
Perform alignment verification after 24hrs of continuous operation.
| Property | Property Value |
|---|---|
| sku | F-SI80H |
