Airtac GAF Filter GAF20006A
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF20006A Filter Unit Technical Details
- Model: GAF20006A
- Type: Auto-drain compressed air filter
- Filtration grade: 5 μm (multi-layer glass fiber)
- Maximum flow rate: 2000 L/min (at 0.7 MPa)
- Operating pressure: 0.15–1.0 MPa
- Port size: PT3/8 (G1/8 optional)
- Bowl material: Polycarbonate (impact-resistant)
- Drain type: Semi-automatic float drain
- Temperature range: 2℃ to 60℃
- Weight: 480g ±5% (dry)
- Dimensions: 98mm(H) × 60mm(Dia) bowl / 32mm(H) head
- Pressure loss: ≤0.02 MPa (at rated flow)
- Moisture removal efficiency: ≥95% (RH 100% input)
High-capacity coalescing filter with visible bowl design, engineered for industrial air preparation systems. Features a vortex-generating baffle plate for centrifugal separation of liquid contaminants and a sintered brass pre-filter screen. The anti-static bowl prevents particle adhesion, while the safety lock ring ensures secure assembly under pressure fluctuations.
- Pneumatic tool air inlet protection
- Paint spray booth air supply conditioning
- CNC machine pneumatic circuit pre-filtration
- Food packaging line moisture control
- Laboratory instrument air purification
Maintenance protocol:
Replace filter element every 4,000 operational hours or when pressure drop exceeds 0.05 MPa.
Always depressurize system before rotating bowl for servicing. Compatible with ISO 8573-1 Class 3 air quality standards.
| Property | Property Value |
|---|---|
| sku | GAF20006A |
| Port Size | PT1/8 |
