Airtac GAF Filter GAF20006AJ
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF20006AJ Filter Specifications
- Model: GAF20006AJ
- Type: Auto-drain compressed air filter
- Port size: PT1/4 (BSP 1/4")
- Flow capacity: 1,500 L/min (ANR)
- Operating pressure: 0.15–1.0 MPa
- Filtration grade: 5 μm (with 40μm bypass protection)
- Maximum humidity removal: 80% (at 0.7MPa)
- Weight: 215g ±5g (dry element)
- Dimensions: 98mm(H) × 65mm(Dia) × 72mm(Width with bracket)
- Bowl material: Polycarbonate (impact-resistant)
- Temperature range: 5℃ to 60℃ (non-freezing)
- Pressure drop: ≤0.03MPa (at rated flow)
- Drain type: Semi-automatic float drain
High-efficiency coalescing filter with dual-stage filtration for industrial air preparation systems. Features a transparent bowl with metal guard, chemical-resistant seals (Viton option available), and anti-re-entrainment design to prevent secondary contamination. Rated for continuous operation with 0.5L water holding capacity.
- CNC machine tool pneumatic lines
- Paint spray booth air supply systems
- Food packaging machinery (FDA-compliant versions)
- Laser cutting machine air knives
- Semiconductor cleanroom air controls
Maintenance protocol:
Replace filter element every 4,000 operating hours or when pressure drop exceeds 0.05MPa.
Always depressurize before bowl removal. Compatible with ISO8573-1 Class 3 air quality standards.
| Property | Property Value |
|---|---|
| sku | GAF20006AJ |
| Port Size | PT1/8 |
