Airtac GAF Filter GAF20006AJW
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF20006AJW Filter Specifications
- Model: GAF20006AJW
- Type: Auto-drain compressed air filter
- Filtration grade: 5 μm (multi-layer coalescing)
- Flow capacity: 2000 L/min (at 0.7 MPa)
- Port size: PT3/8 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa
- Maximum pressure: 1.5 MPa
- Weight: 480g ±5% (with bracket)
- Dimensions: 105mm(Ø) × 165mm(H)
- Housing material: Anodized aluminum alloy
- Filter element: Sintered bronze with PTFE coating
- Temperature range: -20℃ to 60℃ (non-freezing)
- Drain type: Semi-automatic float drain
- Moisture removal efficiency: ≥95% @ 20℃, 70% RH
- Pressure drop: ≤0.02 MPa @ rated flow
- Protection rating: IP54 (standard configuration)
High-efficiency particulate filter with integrated water separation, featuring a dual-chamber design for continuous operation. The centrifugal separation structure enhances liquid removal efficiency while maintaining low pressure drop. Includes a visible contamination indicator (red pop-up alert at 80% capacity). Compatible with ISO 8573-1:2010 Class 3 air quality standards.
- Pneumatic tool air preparation systems
- CNC machine air supply lines
- Automotive painting booth air filtration
- Food packaging machine pneumatic circuits
- Semiconductor manufacturing clean air systems
Maintenance protocol:
Replace element when pressure drop exceeds 0.05 MPa or annually.
Drain bowl should be manually purged weekly in high-humidity environments.
Always install downstream of air dryers and upstream of regulators.
| Property | Property Value |
|---|---|
| sku | GAF20006AJW |
| Port Size | PT1/8 |
