Airtac GAF Filter GAF20006AW
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF Filter GAF20006AW Technical Specifications
- Model: GAF20006AW
- Type: Auto-drain compressed air filter
- Filtration grade: 5μm (βx≥1000)
- Port size: PT1/4 (BSPP)
- Flow capacity: 1,600 NL/min
- Operating pressure: 0.15–1.0 MPa
- Max pressure: 1.5 MPa
- Temperature range: -5℃ to 60℃ (non-freezing)
- Bowl capacity: 120cc
- Drain type: Semi-auto float drain
- Filter element: Sintered bronze (replaceable)
- Housing material: Aluminum alloy (anodized)
- Seal material: NBR rubber
- Weight: 0.68 kg
- Dimensions: 98mm(H) × Φ82mm (bowl diameter)
- Mounting: Bracket rotation 340° adjustable
- Pressure gauge port: 1/8" NPT optional
High-efficiency coalescing filter with precision 5μm rating, featuring a transparent polycarbonate bowl with metal guard. The unique vortex generator design separates 95% of liquid contaminants before filtration. Semi-automatic drain requires manual activation but maintains sealed operation during pressure fluctuations.
- CNC machine tool pneumatic systems
- Paint spray equipment protection
- Food processing air preparation units
- Laser cutting machine air circuits
- Semiconductor manufacturing clean air supply
Maintenance tip:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.07MPa.
Always depressurize before bowl removal. Use thread sealant on male ports (NOT Teflon tape).
| Property | Property Value |
|---|---|
| sku | GAF20006AW |
| Port Size | PT1/8 |
