Airtac GAF Filter GAF20008
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF20008 Pneumatic Filter Specifications
- Model: GAF20008
- Type: Auto-drain compressed air filter
- Filtration grade: 5 μm (40μm optional with mesh insert)
- Flow capacity: 2000 L/min (at 0.7 MPa)
- Operating pressure: 0.15–1.0 MPa
- Port size: PT3/4 (G3/4 optional)
- Body material: Anodized aluminum alloy
- Bowl material: Impact-resistant polycarbonate
- Drain type: Semi-automatic float drain
- Temperature range: -20℃ to 60℃
- Weight: 1.2 kg (with bowl)
- Dimensions: 160mm(H) × 85mm(Diameter) × 85mm(Bowl width)
- Pressure loss: ≤0.02 MPa (at rated flow)
- Moisture separation efficiency: ≥80%
High-efficiency coalescing filter with visible bowl design for industrial air preparation systems. Features dual-stage filtration with centrifugal separation and element filtration, optimized for removing water aerosols and particulate contaminants. The 360° transparent bowl allows easy inspection of contamination levels without disassembly.
- Pneumatic tool air supply lines
- Food processing pneumatic controls
- CNC machine air blast systems
- Automotive painting robots
- Semiconductor manufacturing equipment
Maintenance tip:
Replace filter element every 4,000 operating hours or when pressure drop exceeds 0.05 MPa.
Always depressurize system before bowl removal. Install vertically with arrow marking aligned to airflow direction.
