Airtac GAF Filter GAF20008J
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF20008J Filter Regulator Specifications
- Model: GAF20008J
- Type: Micro-filter regulator with auto-drain
- Filtration grade: 5 μm (ISO8573-1 class 5)
- Maximum pressure: 1.0 MPa
- Flow capacity: 2000 NL/min (ANR)
- Port size: PT1/4 (G1/4 optional)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR + Fluororubber hybrid
- Operating temperature: -5℃ to 60℃ (no freeze)
- Weight: 280g ±5%
- Dimensions: 98mm(H) × 52mm(W) × 82mm(D)
- Drain type: Semi-auto float drain
- Pressure gauge: Built-in 1/8" gauge port
Precision air preparation unit combining filtration and pressure regulation, featuring dual-chamber design for stable output. The sintered bronze filter element captures aerosols and particulates while maintaining 92% filtration efficiency. Corrosion-resistant construction with visible bowl design allows quick contamination checks.
- Pneumatic control systems in CNC machinery
- Air brake systems for material handling equipment
- Laboratory instrument air supply lines
- Packaging machine actuator protection
- Semiconductor manufacturing clean air supply
Installation guidelines:
Mount vertically with arrow direction matching airflow.
Maintain 50mm clearance below bowl for drainage access.
Pre-charge system with 0.05MPa before full operation.
| Property | Property Value |
|---|---|
| sku | GAF20008J |
| Port Size | PT1/4 |
