Airtac GAF Filter GAF20008JW
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF20008JW Filter Specifications
- Model: GAF20008JW
- Type: Auto-drain compressed air filter
- Filtration grade: 5μm (with optional 0.3μm upgrade)
- Flow capacity: 3,500 NL/min (at 0.7MPa)
- Operating pressure: 0.15–1.0 MPa
- Port size: PT1/2 (BSPP) female thread
- Weight: 520g ±5% (dry element)
- Dimensions: 105mm(H) × 68mm(D) × 68mm(W)
- Housing material: Anodized aluminum alloy
- Filter element: Sintered bronze (replaceable)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure loss: ≤0.02MPa (at rated flow)
- Drain type: Semi-automatic float drain
High-efficiency coalescing filter with dual-stage separation technology, featuring a vortex generator for optimal moisture removal. The chrome-free anodized body ensures corrosion resistance in humid environments. Integrated pressure gauge port (G1/8) allows system monitoring without additional adapters.
- Pneumatic tool air preparation systems
- Industrial robot end-effector air supply
- CNC machine coolant mist elimination
- Pharmaceutical cleanroom air lines
- Beverage filling machine pneumatic circuits
Maintenance protocol:
Replace element when pressure drop exceeds 0.07MPa.
Drain bowl should be manually purged weekly in high-humidity environments.
Use only AirTAC P/N FAE20008 replacement elements.
| Property | Property Value |
|---|---|
| sku | GAF20008JW |
| Port Size | PT1/4 |
