Airtac GAF Filter GAF20008W
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF20008W Filter Specifications
- Model: GAF20008W
- Type: Auto-drain compressed air filter
- Filtration grade: 5 μm (with optional 0.3 μm upgrade)
- Flow capacity: 2000 L/min (at 0.7 MPa)
- Operating pressure: 0.15–1.0 MPa
- Port size: PT1/2 (G1/2 optional)
- Body material: Anodized aluminum alloy
- Bowl material: Impact-resistant polycarbonate
- Temperature range: -20℃ to 60℃
- Drain type: Semi-automatic float drain
- Weight: 1.8 kg (with bowl)
- Dimensions: 160mm(H) × 80mm(W) × 80mm(D)
- Pressure loss: ≤0.05 MPa (at rated flow)
- Protection rating: IP54 (bowl impact resistance 1.5J)
High-efficiency coalescing filter with visible bowl design for compressed air systems. Features multi-stage filtration including centrifugal separation and depth filtration elements. The transparent bowl allows visual monitoring of contamination levels, while the semi-automatic drain prevents liquid accumulation. Corrosion-resistant construction ensures durability in humid environments.
- Pneumatic tool air preparation systems
- CNC machine air supply lines
- Paint spray booth air filtration
- Food processing pneumatic controls
- Semiconductor manufacturing clean air supply
Maintenance note:
Replace filter element every 4,000 operating hours or when pressure drop exceeds 0.1 MPa.
Always depressurize system before bowl removal. Compatible with ISO 8573-1 Class 3 air quality standards.
| Property | Property Value |
|---|---|
| sku | GAF20008W |
| Port Size | PT1/4 |
