Airtac GAF Filter GAF200C06
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF200C06 Filter Regulator Specifications
- Model: GAF200C06
- Type: Auto-drain micro-filter regulator
- Filtration grade: 5 μm (0.3μm optional with coalescing element)
- Flow capacity: 2000 NL/min (at 0.7 MPa)
- Port size: PT1/4 (G1/4 available)
- Operating pressure: 0.15–1.0 MPa
- Maximum pressure: 1.5 MPa
- Body material: Die-cast aluminum (anodized)
- Bowl material: Polycarbonate (metal bowl optional)
- Temperature range: -5℃ to 60℃ (with anti-freeze drain)
- Drain type: Semi-automatic float drain
- Pressure gauge: Built-in 1/8" port (0-1.6 MPa scale)
- Weight: 580g ±10g
- Dimensions: 140mm(H) × 60mm(W) × 85mm(D)
- Protection rating: IP54 (IP65 with optional cover)
High-efficiency compressed air treatment unit combining filtration and pressure regulation. Features a visible bowl with safety shield, corrosion-resistant construction, and bubble-tight shutoff. The 360° rotatable bracket allows flexible installation orientations. Requires 50% less maintenance than standard filters due to vortex-inducing bowl design.
- Pneumatic actuator protection in CNC machinery
- Air preparation for precision painting systems
- Food processing pneumatic lines (FDA-compliant versions available)
- Semiconductor manufacturing cleanrooms
- Laser cutting machine air knife systems
Maintenance protocol:
Replace element every 6,000 operating hours or when pressure drop exceeds 0.07 MPa.
Always depressurize system before bowl removal. Use only AirTAC P/N FF5002 filter elements.
| Property | Property Value |
|---|---|
| sku | GAF200C06 |
| Port Size | PT1/8 |
