Airtac GAF Filter GAF200C06A
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF200C06A Filter Regulator Specifications
- Model: GAF200C06A
- Type: Auto-drain compressed air filter with regulator
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa
- Max flow rate: 2000 L/min (ANR)
- Filtration grade: 5 μm (40μm optional element available)
- Water removal efficiency: ≥95% @ 0.7MPa
- Weight: 0.82 kg
- Dimensions: 150mm(L) × 70mm(W) × 70mm(H)
- Housing material: Anodized aluminum alloy
- Filter element: Hydrophobic polyester fiber
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.6MPa range)
- Adjustment knob: Lockable rotary type with ±2% accuracy
High-efficiency coalescing filter with integrated pressure regulation, featuring automatic float-type drainage for continuous moisture elimination. The multi-stage filtration system combines centrifugal separation and depth filtration, optimized for industrial environments with oil-contaminated or humid compressed air.
- Pneumatic tool air preparation systems
- Food packaging machinery air lines
- Automotive painting booth air supply
- CNC machine pneumatic controls
- Pharmaceutical manufacturing clean air systems
Maintenance advisory:
Replace filter element every 4,000 operational hours or when pressure drop exceeds 0.1MPa.
Manual drain override available via push-button actuator. Install vertically with 50mm clearance
below drain port for maintenance access.
| Property | Property Value |
|---|---|
| sku | GAF200C06A |
| Port Size | PT1/8 |
