Airtac GAF Filter GAF200C06AJW
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF200C06AJW Filter Regulator Specifications
- Model: GAF200C06AJW
- Type: Auto-drain micro-filter regulator with pressure gauge
- Filtration grade: 5 μm (ISO 8573-1 Class 3)
- Flow capacity: 2000 L/min (ANR)
- Operating pressure: 0.05–1.0 MPa
- Port size: PT1/4 (G1/4 optional)
- Body material: Die-cast aluminum alloy (anodized)
- Bowl material: Polycarbonate (impact-resistant)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Semi-automatic float drain
- Gauge range: 0–1.6 MPa (360° rotatable)
- Weight: 350g ±5% (dry)
- Dimensions: 105mm(H) × 70mm(W) × 70mm(D)
- Pressure adjustment: Lockable knob with ±2% accuracy
- Protection rating: IP40 (bowl cover meets NEMA 4)
Precision air preparation unit combining filtration and pressure regulation, featuring a visible bowl design for debris monitoring. The dual-stage filtration system removes liquid aerosols and particulate contaminants while maintaining stable downstream pressure. Includes a tamper-proof adjustment knob and safety relief valve.
- Pneumatic tool air supply systems
- Food processing pneumatic lines (NSF compliant)
- Laboratory instrument air purification
- Packaging machine actuator controls
- CNC machine air blast circuits
Maintenance tip:
Replace filter element every 2,000 operating hours or when pressure drop exceeds 0.05 MPa.
Always depressurize system before bowl removal. Use only silicone-free lubricants if required.
| Property | Property Value |
|---|---|
| sku | GAF200C06AJW |
| Port Size | PT1/8 |
