Airtac GAF Filter GAF200C06AW
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF200C06AW Filter Regulator Specifications
- Model: GAF200C06AW
- Type: Auto-drain compressed air filter with regulator
- Port size: PT1/4 (G1/4 optional)
- Filtration grade: 5 μm (multi-layer glass fiber element)
- Operating pressure: 0.15–1.0 MPa
- Max flow rate: 1,000 NL/min
- Weight: 0.52 kg (with bracket)
- Dimensions: 98mm(L) × 76mm(W) × 118mm(H)
- Bowl material: Impact-resistant polycarbonate
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Semi-automatic float drain
- Pressure gauge: Built-in 1/8" dial gauge (optional)
High-efficiency coalescing filter with integrated pressure regulation, featuring a transparent bowl with anti-static coating to prevent particle adhesion. The dual-stage design separates 95% of liquid contaminants and 99.5% of particles ≥5μm. The W-suffix indicates winter configuration with freeze-resistant seals.
- Pneumatic tool air preparation systems
- Industrial robot end-effector controls
- CNC machine pneumatic circuits
- Food packaging line air supply
- Laser cutting machine gas filtration
Maintenance protocol:
Replace element every 6,000 operating hours or when pressure drop exceeds 0.07MPa.
Always depressurize system before rotating the regulator knob (yellow top).
| Property | Property Value |
|---|---|
| sku | GAF200C06AW |
| Port Size | PT1/8 |
