Airtac GAF Filter GAF200C06J
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF200C06J Filter Regulator Specifications
- Model: GAF200C06J
- Type: Auto-drain compressed air filter with pressure regulation
- Port size: PT3/8 (G3/8 optional)
- Flow capacity: 2000 L/min (ANR)
- Filtration grade: 5μm (ISO8573-1 class 5)
- Operating pressure: 0.15–1.0 MPa
- Max pressure: 1.5 MPa
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Semi-automatic float drain
- Body material: Die-cast aluminum (anodized)
- Bowl material: Polycarbonate (impact-resistant)
- Filter element: Hydrophobic polyester fiber
- Weight: 0.82 kg (dry)
- Dimensions: 98mm(Ø) × 165mm(H) (excluding bracket)
High-efficiency coalescing filter with integrated pressure regulator, featuring a transparent bowl with 360° visibility. The vortex-inducing design separates 95%+ liquid contaminants and 5μm particulates. Includes a manual blow-down button and tamper-proof adjustment knob. Meets ISO 8573-1 Class 5 standards for compressed air purity.
- Pneumatic tool air preparation systems
- CNC machine air line protection
- Packaging machinery moisture control
- Robotic actuator air supply conditioning
- Dental chair pneumatic circuits
Maintenance protocol:
Replace filter element every 8,000 operating hours or when pressure drop exceeds 0.07MPa.
Drain bowl daily in high-humidity environments. Install vertically with 50mm clearance
below for drain operation. Use PTFE tape on male threads only.
| Property | Property Value |
|---|---|
| sku | GAF200C06J |
| Port Size | PT1/8 |
