Airtac GAL Lubricator GAL20008
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL20008 Automatic Lubricator Specifications
- Model: GAL20008
- Type: Micro-drip oil feeder with adjustable flow
- Capacity: 200ml (transparent polycarbonate reservoir)
- Flow rate: 0.5-3.0ml/day (continuously adjustable)
- Oil viscosity range: ISO VG32-VG220 (22-460 cSt)
- Operating pressure: 0.05-1.0 MPa
- Port connection: PT1/8 (G1/8 optional)
- Body material: Anodized aluminum alloy
- Temperature range: 0℃ to 60℃ (non-freezing)
- Weight: 520g ±5% (empty)
- Dimensions: 115mm(H) × 78mm(W) × 142mm(L)
- Drip window: 360° rotatable observation port
- Mounting: Vertical installation required
Precision pneumatic line lubricator featuring dual-stage filtration (40μm + 100 mesh) and anti-backflow design. The visible oil chamber allows real-time monitoring, while the knurled flow adjustment knob enables precise lubrication control without tools. Integrated check valve prevents oil reservoir pressurization.
- Pneumatic tool maintenance systems
- Packaging machinery cylinder lubrication
- Automated production line air preparation units
- Textile machinery pneumatic circuits
- Food processing equipment (food-grade oil compatible)
Installation note:
Always install downstream of FRL units with minimum 300mm straight piping before lubricator.
Refill when oil level drops below 1/3 capacity. Rotate drip window to optimal viewing angle during commissioning.
| Property | Property Value |
|---|---|
| sku | GAL20008 |
| Port Size | PT1/4 |
