Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Maintenance protocol:
Replace bowl every 2 years or 10,000 operating hours. Use only neutral
detergents for cleaning. Prime with 50 drops before initial operation.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL200C08J Automatic Lubricator Specifications
- Model: GAL200C08J
- Type: Micrometer-adjustable pneumatic lubricator
- Flow capacity: 200 NL/min (at 0.7MPa)
- Oil delivery adjustment: 0-60 drops/min (visual indicator)
- Port size: PT1/8 (BSP1/8 compatible)
- Oil reservoir capacity: 300cc
- Operating pressure: 0.2-1.0 MPa
- Recommended oil type: ISO VG32 or equivalent turbine oil
- Weight: 580g ±5% (empty), 850g ±5% (filled)
- Dimensions: 115mm(H) × 75mm(W) × 75mm(D)
- Body material: Anodized aluminum alloy
- Transparent bowl: Polycarbonate (PC)
- Temperature range: 5℃ to 60℃ (operating fluid)
- Mounting orientation: Vertical ±15°
Precision pneumatic line lubricator featuring drip-rate magnification window and anti-clogging mechanism. The dual-chamber design maintains consistent oil supply during refills. Includes built-in check valve to prevent reverse flow. Rated for 500,000 cycles minimum.
Typical Applications:
- Pneumatic tool lubrication systems
- Automated assembly line actuators
- Packaging machinery air circuits
- Food processing pneumatic controls (food-grade oil compatible)
- Automotive painting robot maintenance
Maintenance protocol:
Replace bowl every 2 years or 10,000 operating hours. Use only neutral
detergents for cleaning. Prime with 50 drops before initial operation.
Configuration tip: Install downstream of FRL units,
300-500mm from protected components. For horizontal piping runs,
use optional GAS-12M mounting bracket (sold separately).
| Property | Property Value |
|---|---|
| sku | GAL200C08J |
| Port Size | PT1/4 |
