Airtac GAL Lubricator GAL200N08J
$24.62
Regular price
$32.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAL200N08J
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Installation note:
Mount vertically within 5° tolerance downstream of FRL units.
Maintain oil level between 30-80% capacity. Replace oil annually
or every 2,000 operating hours. Use anti-vibration bracket in
high-shock environments.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL200N08J Automatic Lubricator Specifications
- Model: GAL200N08J
- Type: Pressure-feed adjustable lubricator
- Capacity: 200cc (transparent polycarbonate oil cup)
- Operating pressure: 0.05–1.0 MPa
- Oil flow adjustment: 5-60 drops/min (micrometer control)
- Port size: PT1/8 (BSP1/8) female threads
- Weight: 450g ±5% (empty)
- Dimensions: 110mm(L) × 75mm(W) × 75mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: 0℃ to 60℃ (operating fluid)
- Viscosity range: ISO VG32–VG220 turbine oil
- Protection rating: IP54 (dust/water resistant)
Precision air line lubricator with visual oil level indicator and drip observation window. Features anti-clogging needle valve design and pressure-balanced oil feed system. Includes built-in check valve to prevent reverse flow. Requires ISO 32-220 grade turbine oil (petroleum-based).
Typical Applications:
- Pneumatic tool maintenance systems
- Packaging machinery cylinder lubrication
- Industrial pressurization systems
- Automated assembly line actuators
- CNC machine pneumatic circuits
Installation note:
Mount vertically within 5° tolerance downstream of FRL units.
Maintain oil level between 30-80% capacity. Replace oil annually
or every 2,000 operating hours. Use anti-vibration bracket in
high-shock environments.
| Property | Property Value |
|---|---|
| sku | GAL200N08J |
| Port Size | PT1/4 |
