Airtac GAL Lubricator GAL30010
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAL30010
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Installation note:
Mount vertically downstream of FRL units. Maintain minimum 150mm clearance below bowl for maintenance.
Refill when oil level drops below 20% capacity. Use only recommended non-foaming ISO turbine oils.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL30010 Automatic Lubricator Specifications
- Model: GAL30010 (GAL Series)
- Type: Micrometer-adjustable pneumatic lubricator
- Port size: 1/4" BSPP (G1/4)
- Operating pressure: 0.3–1.0 MPa
- Oil capacity: 300 cm³
- Oil viscosity range: ISO VG32–VG680 (10–3000 cSt)
- Body material: Anodized aluminum alloy
- Bowl material: Transparent polycarbonate
- Temperature range: 5℃ to 60℃ (fluid dependent)
- Drip rate adjustment: 1–60 drops/min
- Weight: 850g ±5% (empty)
- Dimensions: 155mm(H) × 90mm(Dia.)
- Connection type: Bracket-mounted with bypass check valve
High-visibility lubricator featuring precision needle valve control and corrosion-resistant construction. The dual-stage filtration system includes a 40μm inlet strainer and replaceable 25μm filter element. Integrated pressure relief prevents over-lubrication during system shutdowns.
Typical Applications:
- Pneumatic cylinder maintenance systems
- Industrial automation assembly lines
- Packaging machinery lubrication stations
- CNC machine tool air preparation units
- Railway braking systems
Installation note:
Mount vertically downstream of FRL units. Maintain minimum 150mm clearance below bowl for maintenance.
Refill when oil level drops below 20% capacity. Use only recommended non-foaming ISO turbine oils.
| Property | Property Value |
|---|---|
| sku | GAL30010 |
| Port Size | PT3/8 |
