Airtac GAL Lubricator GAL30010J
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL30010J Lubricator Specifications
- Model: GAL30010J
- Type: Micromist adjustable lubricator with transparent bowl
- Capacity: 300cc (0.32 quarts)
- Operating pressure: 0.05-1.0 MPa (7-145 PSI)
- Oil output: 5-60 drops/min (precision adjustable knob)
- Port size: 1/4" NPT female (BSPP optional)
- Body material: Anodized aluminum alloy
- Bowl material: Impact-resistant polycarbonate
- Temperature range: 0℃ to 60℃ (32℉-140℉)
- Weight: 520g (1.15 lbs) with empty bowl
- Dimensions: 98mm(H) × 82mm(W) × 138mm(D)
- Viscosity range: ISO VG32-220 (SAE 10-90)
- Air consumption: ≤0.5 NL/min at 0.5MPa
Professional-grade pneumatic lubricator featuring triple-stage filtration (40μm stainless mesh + sintered bronze + vortex separation) for contamination-free oil mist delivery. Integrated check valve prevents reverse flow, with visual oil level indicator and drip window for real-time monitoring. Compatible with most ISO-L-AGC/PDO oils.
- CNC machine pneumatic tool lubrication
- Assembly line pneumatic actuator maintenance
- Food processing equipment (FDA-grade oil compatible)
- High-cycle pneumatic presses and stamping machines
- Railway braking systems
Maintenance protocol:
Refill when oil level drops below 20% capacity. Replace bowl every 2,000 operating hours or if surface cracks appear. Always pressurize system before adjusting flow rate.
| Property | Property Value |
|---|---|
| sku | GAL30010J |
| Port Size | PT3/8 |
