Airtac GAL Lubricator GAL300C10J
$29.06
Regular price
$36.56
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAL300C10J
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Installation note:
Mount downstream of FRL units with minimum 300mm straight piping before lubricator.
Prime the unit by rotating adjustment knob fully clockwise before initial operation.
Replace bowl every 2 years or after 5,000 operating hours.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300C10J Automatic Lubricator Specifications
- Model: GAL300C10J
- Type: Pneumatic system oil feeder (drip-feed type)
- Capacity: 300cc transparent reservoir
- Operating pressure: 0.3–1.0 MPa
- Oil output adjustment: 0.1–6 drops/min (rotary dial control)
- Port connections: Rc1/4 (BSPP 1/4")
- Body material: Polycarbonate (PC) with aluminum alloy brackets
- Temperature range: 5℃ to 60℃ (operating fluid temp)
- Weight: 0.62kg (empty), 0.92kg (filled)
- Dimensions: 100mm(L) × 75mm(W) × 120mm(H)
- Oil viscosity range: ISO VG32–VG68
- Mounting orientation: Vertical ±15°
- Filter element: 40μm stainless steel mesh
High-visibility lubricator with precise metering control, featuring anti-corrosion internals and bubble-free oil delivery. The dual-chamber design prevents oil backflow during pressure fluctuations. Requires ISO-grade turbine oil and upstream air filtration (5μm recommended).
Typical Applications:
- Pneumatic cylinder maintenance systems
- Assembly line tooling lubrication
- Food processing pneumatic circuits (food-grade oil compatible)
- Textile machinery air preparation units
- Automotive painting robot actuators
Installation note:
Mount downstream of FRL units with minimum 300mm straight piping before lubricator.
Prime the unit by rotating adjustment knob fully clockwise before initial operation.
Replace bowl every 2 years or after 5,000 operating hours.
| Property | Property Value |
|---|---|
| sku | GAL300C10J |
| Port Size | PT3/8 |
