Airtac GAL Lubricator GAL300C15
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300C15 Automatic Lubricator Specifications
- Model: GAL300C15
- Type: Micrometer-adjustable pneumatic lubricator
- Oil capacity: 15cc (0.5oz)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Maximum flow rate: 300 NL/min
- Oil droplet adjustment: 5-60 drops/min (micrometer control)
- Body material: Polycarbonate + Aluminum alloy
- Weight: 210g (without oil)
- Dimensions: Φ60mm × 100mm(H)
- Inlet/Outlet ports: Rc1/4 (BSPP 1/4")
- Temperature range: -10℃ to 60℃ (14℉ to 140℉)
- Oil viscosity range: ISO VG32-68 (SAE 10-20)
- Moisture resistance: 95% RH max (non-condensing)
Precision air line lubricator with visible oil level window and corrosion-resistant construction. Features a unique cyclone oil-mixing design for consistent aerosol delivery. Includes anti-backflow check valve and sintered bronze filter (40μm). Requires ISO VG32 turbine oil or equivalent.
- Pneumatic tool maintenance systems
- Industrial cylinder lubrication networks
- Packaging machine pneumatic circuits
- Automated assembly line air preparation
- Food processing plant compressed air systems (food-grade oil compatible)
Installation protocol:
Mount vertically downstream of filter-regulator (FRL unit). Maintain 20cm clearance below
for oil cup removal. Prime by rotating adjustment knob clockwise until resistance is felt
before initial operation.
| Property | Property Value |
|---|---|
| sku | GAL300C15 |
| Port Size | PT 1/2 |
