Airtac GAL Lubricator GAL300N08
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300N08 Automatic Lubricator Specifications
- Model: GAL300N08
- Type: Micrometer adjustable drip-feed lubricator
- Flow rate adjustment: 5-60 drops/min (visual indicator)
- Fluid compatibility: ISO VG32 or equivalent turbine oils
- Operating pressure: 0.2-1.0 MPa
- Oil capacity: 300ml (transparent polycarbonate reservoir)
- Port connections: PT1/4 (BSPP thread standard)
- Weight: 850g ±3% (empty reservoir)
- Dimensions: 120mm(H) × 80mm(W) × 65mm(D)
- Temperature range: 5℃ to 60℃ (non-freezing conditions)
- Orientation: Vertical installation required (±5° tolerance)
- Filter element: 40μm stainless steel mesh (replaceable)
- Drip window: Impact-resistant PMMA with UV protection
Precision pneumatic line lubricator featuring corrosion-resistant aluminum alloy body and vacuum-assisted oil delivery. The dual-chamber design prevents oil backflow during pressure fluctuations. Includes integrated check valve and splash guard for stable lubrication in high-vibration environments. Requires ISO cleanliness code 18/16/13 compressed air.
- CNC machine pneumatic tool changers
- Automated assembly line cylinder maintenance
- Food packaging machinery (food-grade oil compatible)
- Railway braking systems
- Plastic injection molding machine air circuits
Maintenance protocol:
Refill when oil level drops below 20% capacity. Perform monthly bowl drainage
using the bottom sediment release valve. Replace filter cartridge every 2,000
operating hours or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | GAL300N08 |
| Port Size | PT1/4 |
