Airtac GAL Lubricator GAL300N10
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300N10 Automatic Lubricator Specifications
- Model: GAL300N10
- Type: Pneumatic line lubricator with oil mist control
- Capacity: 300cc (10oz)
- Port size: PT1/4 (NPT1/4 optional)
- Operating pressure: 0.2–0.7 MPa (29–102 PSI)
- Oil viscosity range: ISO VG32–VG68 (SAE 10–20)
- Flow adjustment: 0–60 drops/min (knob-controlled)
- Material: PC oil reservoir, brass fittings
- Weight: 800g (1.76 lbs) with empty reservoir
- Dimensions: Ø80mm × 150mm (3.15" dia × 5.91" H)
- Temperature range: 0℃ to 60℃ (32℉ to 140℉)
- Transparency: 85% visible oil level window
- Protection rating: IP54 (dust/water resistant)
High-precision pneumatic lubricator featuring micro-adjustment valve for controlled oil mist delivery. The polycarbonate reservoir offers excellent visibility and chemical resistance, while the vortex chamber design ensures stable oil supply even under pressure fluctuations. Includes anti-backflow check valve and sintered bronze filter (40μm).
- Pneumatic tool lubrication systems
- Automated assembly line actuators
- Packaging machinery cylinder maintenance
- Food processing pneumatic circuits (food-grade oil compatible)
- CNC machine air preparation units
Installation note:
Mount vertically downstream of filter-regulator (F.R.L. unit).
Fill reservoir to 80% capacity maximum. Adjust oil feed rate after
5 minutes of system pressurization. Replace filter element every
2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | GAL300N10 |
| Port Size | PT3/8 |
