Airtac GAL Lubricator GAL300N15
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300N15 Automatic Lubricator Specifications
- Model: GAL300N15
- Type: Micro-drip automatic oil feeder with adjustable flow
- Capacity: 300cc transparent reservoir
- Operating pressure: 0.2–1.0 MPa
- Oil viscosity range: 30-1500 cSt (ISO VG32~VG1500)
- Port size: Rc1/4 (NPT1/4 optional)
- Body material: Anodized aluminum alloy
- Seal material: NBR/Viton hybrid
- Temperature range: -10℃ to 60℃
- Weight: 280g (empty) / 580g (filled)
- Dimensions: 82mm(L) × 65mm(W) × 118mm(H)
- Drip rate adjustment: 1-60 drops/min (rotary dial)
- Maximum flow: 3.5cc/min
Precision oil metering device with visible oil level window, designed for continuous lubrication in pneumatic systems. Features anti-clogging ceramic nozzle and corrosion-resistant construction. Includes built-in check valve to prevent backflow. Requires ISO VG32 or equivalent turbine oil (mineral-based).
- Pneumatic cylinder maintenance systems
- Air tool lubrication stations
- Packaging machine chain lubricators
- CNC machine air line conditioning
- Industrial robotic actuator maintenance
Installation note:
Mount vertically within 500mm downstream of air preparation units.
Prime unit by rotating adjustment knob clockwise until oil appears in sight glass.
Replace oil annually or when contamination exceeds ISO 4406 18/16/13.
| Property | Property Value |
|---|---|
| sku | GAL300N15 |
| Port Size | PT 1/2 |
