Airtac GAL Lubricator GAL300N15J
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300N15J Auto Lubricator Specifications
- Model: GAL300N15J
- Type: Pneumatic oil feeder with micro-flow adjustment
- Capacity: 300cc
- Port size: Rc1/8 (NPT1/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Oil output range: 0.5–3.0 cc/h (continuously adjustable)
- Body material: Transparent polycarbonate + anodized aluminum
- Weight: 480g ±5% (empty)
- Dimensions: 98mm(H) × 72mm(W) × 72mm(D)
- Temperature range: 0℃ to 60℃ (operation), -10℃ to 70℃ (storage)
- Viscosity range: 10–1500 cSt (ISO VG15-VG1500)
- Drip visibility: 360° transparent chamber with magnified scale
- Mounting: Bracket included for vertical installation
Precision oil metering device featuring a dual-chamber design with anti-clog needle valve. The corrosion-resistant aluminum base integrates a built-in check valve to prevent oil backflow. Optimized for ISO 32-220 turbine oils, with visual oil level indicators and tool-free refill cap. Requires 40μm filtered air supply.
- Pneumatic cylinder lubrication in automated assembly lines
- Air tool maintenance systems
- Food-grade machinery (when using NSF H1 lubricants)
- Textile machine pneumatic circuits
- Railway brake system lubrication
Maintenance tip:
Perform monthly diaphragm inspection and annual O-ring replacement.
Always maintain oil level above 20% capacity to prevent air mixing.
For cold environments below 5℃, pre-heat oil to 25℃ before refilling.
| Property | Property Value |
|---|---|
| sku | GAL300N15J |
| Port Size | PT 1/2 |
