Airtac GAR Air Regulator GAR20006L
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20006L Precision Pressure Regulator Specifications
- Model: GAR20006L (with integrated pressure gauge)
- Type: Pilot-operated pressure regulator with lockable knob
- Port size: PT1/4 (BSPP thread standard)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow capacity: 2500 L/min (ANR)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) with optional FKM seals
- Temperature range: -20℃ to 70℃ (non-freezing conditions)
- Weight: 450g ±5% (including gauge)
- Dimensions: 120mm(L) × 50mm(W) × 60mm(H)
- Gauge range: 0–1.0 MPa (dual scale: MPa & psi)
- Pressure adjustment sensitivity: ±0.01 MPa
- Operating medium: Filtered compressed air (ISO 8573-1:2010 Class 3)
Industrial-grade pressure regulator featuring a tamper-resistant adjustment knob and corrosion-resistant construction. The integrated 360° rotatable gauge allows flexible installation in confined spaces. Designed for systems requiring stable pressure maintenance even under fluctuating flow conditions.
- Pneumatic conveyor line pressure stabilization
- Packaging machine clamping force control
- Automated assembly tooling pressure management
- Textile machinery air pressure regulation
- Food processing equipment (requires optional FKM seals)
Installation guidelines:
Mount vertically with arrow direction matching airflow. Always install downstream of a 5μm filter.
For pulsation reduction, maintain 10x port diameter straight tubing before regulator inlet.
| Property | Property Value |
|---|---|
| sku | GAR20006L |
| Port Size | PT1/8 |
