Airtac GAR Air Regulator GAR20006LJK
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20006LJK Precision Pressure Regulator Specifications
- Model: GAR20006LJK
- Type: Pilot-operated pressure regulator with lockable knob
- Port size: PT1/4 (BSPP thread)
- Pressure range: 0.05–0.85 MPa (7–123 PSI)
- Max flow capacity: 1,200 NL/min (ANR)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Operating temperature: -5℃ to 60℃ (with 0℃ anti-freeze measures)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 80mm(W) × 50mm(H) × 45mm(D)
- Pressure gauge: Integrated 1/8" NPT gauge port
- Adjustment knob rotation: 270° with click-stop mechanism
- Relief function: Built-in overflow bypass
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The zinc-plated spring chamber and chrome-plated piston ensure corrosion resistance in humid environments. Includes a tamper-proof adjustment knob with torque limiter (3.5 N·m max).
- Pneumatic conveyor line pressure stabilization
- Robotic gripper force control systems
- Plastic injection molding machine air circuits
- CNC machine tool clamping pressure regulation
- Food processing pneumatic actuator control
Installation note:
Install downstream of filter/lubricator (FRL) units. For vertical mounting,
orient gauge port upward. Perform pressure adjustments under flow conditions
(≥5 L/min) for accurate calibration. Replace desiccant cartridges every
2,000 operating hours in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GAR20006LJK |
| Port Size | PT1/8 |
