Airtac GAR Air Regulator GAR20006LJN
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20006LJN Precision Pressure Regulator Specifications
- Model: GAR20006LJN
- Type: Miniature locking-type pressure regulator
- Port size: 1/4" NPT (G1/4 optional)
- Pressure range: 0.05–0.85 MPa
- Max pressure: 1.0 MPa
- Operating temperature: -5℃ to 80℃
- Body material: Aluminum alloy (anodized finish)
- Diaphragm: NBR rubber reinforced with nylon mesh
- Lock mechanism: Rotational lock collar design
- Weight: 340g ±5g
- Dimensions: 82mm(L) × 48mm(W) × 53mm(H)
- Pressure gauge port: M5 threaded (optional gauge mounting)
- Flow capacity: 2000 NL/min
- Repeat accuracy: ±0.02 MPa
Compact pressure regulator featuring a unique dual-stage locking system that prevents accidental adjustment. The corrosion-resistant aluminum body and reinforced diaphragm ensure stable pressure control in vibration-prone environments. Includes a tamper-proof adjustment knob with torque-limiting design (1.2N·m max).
- Robotic end-effector pneumatic systems
- CNC machine tool clamping circuits
- Semiconductor manufacturing equipment
- Food packaging line pressure stabilization
- Laboratory pneumatic instrument calibration
Installation protocol:
Mount in vertical orientation with arrow aligned to airflow direction.
Always install downstream filter (5μm minimum). For optimal performance,
maintain 15mm clearance below regulator for gauge installation.
| Property | Property Value |
|---|---|
| sku | GAR20006LJN |
| Port Size | PT1/8 |
