Airtac GAR Air Regulator GAR20006S
$26.74
Regular price
$34.24
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAR20006S
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC GAR Series Pressure Regulator Technical Specifications:
1. Features snap-fit round pressure gauge with magnifying lens cover for space-saving installation and clear scale visibility;
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
Installation guidelines:
Install downstream of filter/lubricator (FRL unit). For vertical mounting,
orient adjustment knob upward. Perform initial bleeding by rotating knob
counterclockwise 2 full turns before operation.
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20006S Pressure Regulator Technical Details
- Model: GAR20006S (Standard Thread Series)
- Type: Precision pressure regulator with gauge port
- Port size: 1/4" NPT (G1/4 optional)
- Pressure range: 0.05–0.85 MPa
- Max inlet pressure: 1.0 MPa
- Flow capacity: 2000 NL/min
- Accuracy: ±0.008 MPa
- Operating temperature: -5℃ to 60℃ (no freeze)
- Housing material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR rubber (oil-resistant)
- Weight: 0.48 kg ±2%
- Dimensions: 72mm(W) × 85mm(H) × 50mm(D)
- Mounting: Panel mount with M5 screws
- Filtration requirement: 5-40μm filter recommended
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating loads. Includes T-handle lock mechanism and integrated pressure gauge (1/8" NPT gauge port). Corrosion-resistant construction with IP54 splash protection.
Typical Applications:
- Pneumatic conveyor systems
- CNC machine tool air circuits
- Semiconductor manufacturing equipment
- Automated assembly line pressure control
- Packaging machinery air preparation units
Installation guidelines:
Install downstream of filter/lubricator (FRL unit). For vertical mounting,
orient adjustment knob upward. Perform initial bleeding by rotating knob
counterclockwise 2 full turns before operation.
| Property | Property Value |
|---|---|
| sku | GAR20006S |
| Port Size | PT1/8 |
