Airtac GAR Air Regulator GAR20008LN
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20008LN Precision Air Pressure Regulator Specifications
- Model: GAR20008LN
- Type: Precision pressure regulator with gauge port
- Port size: PT1/4 (BSP 1/4)
- Pressure regulation range: 0.05–0.85 MPa
- Maximum flow rate: 2,500 L/min (ANR)
- Operating temperature: -20℃ to 70℃
- Gauge interface: Rc1/8 (optional gauge included)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (nitrile rubber)
- Weight: 600g ±5%
- Dimensions: 130mm(L) × 60mm(W) × 60mm(H)
- Pressure gauge range: 0–1.0 MPa (standard dial type)
- Locking mechanism: Spring-loaded adjustment knob with lock ring
- Filter element: 40μm sintered bronze (replaceable)
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The integrated moisture separator and filter ensure clean air delivery, while the oversized adjustment knob allows precise control even with gloved hands. The corrosion-resistant construction includes a chrome-plated spring chamber and self-lubricating piston assembly.
- Pneumatic production line pressure stabilization
- CNC machine tool air circuit control
- Packaging machinery pressure management
- Industrial robot end-effector systems
- Semiconductor manufacturing equipment
Installation guidelines:
Mount vertically with arrow direction matching airflow. Always install downstream of lubricators.
For optimal performance, pre-charge system to 0.1MPa before adjustment. Replace filter element
every 3,000 operational hours or when pressure drop exceeds 0.02MPa.
- Pull up locking ring to unlock adjustment knob
- Rotate clockwise to increase pressure (view gauge)
- Push down locking ring to secure setting
- Verify stability under load conditions
| Property | Property Value |
|---|---|
| sku | GAR20008LN |
| Port Size | PT1/4 |
