Airtac GAR Air Regulator GAR20008LNK
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR Series Precision Pressure Regulator GAR20008LNK Technical Details
- Full model designation: GAR20008LNK (with lockable handle)
- Type: Pilot-operated precision air pressure regulator
- Port size: PT1/4 (BSPP thread standard)
- Pressure adjustment range: 0.05-0.85 MPa
- Maximum input pressure: 1.0 MPa
- Flow capacity: 2000 NL/min (ANR, at 0.5MPa)
- Operating temperature: -5℃ to 60℃ (no freezing)
- Body material: Aluminum alloy (anodized surface treatment)
- Diaphragm material: NBR synthetic rubber
- Weight: 0.68 kg ±2%
- Dimensions: 102mm(H) × 50mm(W) × 68mm(D)
- Pressure gauge interface: M5 threaded
- Mounting options: Panel mount (requires 45mm cutout) or bracket mounting
- Vibration resistance: ≤49 m/s² (with locked handle)
- Air filtration requirement: 5μm particulate filter recommended
High-sensitivity pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The GAR20008LNK model includes a hexagonal locking mechanism to prevent accidental adjustment, with precision-machined components ensuring ±2% set pressure accuracy. The integrated relief vent allows for downstream pressure release during adjustment.
- Pneumatic actuator control in automated assembly lines
- Air pressure stabilization for CNC machine tooling
- Packaging machinery pressure-sensitive operations
- Laboratory pneumatic instrument calibration systems
- Semiconductor manufacturing cleanroom environments
Installation guidelines:
Install in dry, vibration-minimized locations with vertical orientation.
Always depressurize system before adjusting. For optimal performance,
maintain airflow direction arrow markings and install downstream
lubricator if using oil-mist lubrication systems.
| Property | Property Value |
|---|---|
| sku | GAR20008LNK |
| Port Size | PT1/4 |
