Airtac GAR Air Regulator GAR20008SJK
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20008SJK Precision Pressure Regulator Specifications
- Model: GAR20008SJK
- Type: Precision air pressure regulator with gauge port
- Port size: PT1/4 (BSPP thread)
- Operating pressure range: 0.05–0.85 MPa
- Maximum pressure: 1.0 MPa
- Flow capacity: 2,800 Nl/min (Cv=1.8)
- Accuracy: ±0.08 MPa (within 80% of set pressure)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 520g ±5%
- Dimensions: 100mm(L) × 50mm(W) × 80mm(H)
- Gauge thread: M5×0.8 female
- Pressure adjustment: Knob rotation (360° free)
- Locking mechanism: Push-pull locking collar
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The integrated pressure gauge port allows real-time monitoring, while the ergonomic locking collar prevents accidental setting changes. Optimized diaphragm structure ensures quick response to load variations.
- Pneumatic actuator pressure stabilization
- Assembly line torque control systems
- Packaging machinery pressure sequencing
- CNC machine tool air supply regulation
- Laboratory pneumatic instrument calibration
Installation guidelines:
Install downstream of filter/lubricator (FRL) units. For optimal performance:
- Maintain 10x pipe diameter straight run before inlet
- Drain condensate weekly via bottom exhaust
- Use PTFE tape on male threads only
| Property | Property Value |
|---|---|
| sku | GAR20008SJK |
| Port Size | PT1/4 |
