Airtac GAR Air Regulator GAR20008SJNK
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20008SJNK Precision Pressure Regulator Specifications
- Model: GAR20008SJNK
- Type: Precision air pressure regulator with gauge port
- Port size: PT1/4 (BSPP thread)
- Pressure range: 0.05–0.85 MPa
- Max flow rate: 1,500 NL/min (ANR)
- Operating temperature: 5℃ to 60℃ (no freezing)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (standard), optional FKM
- Weight: 520g ±5g
- Dimensions: 98mm(H) × 50mm(W) × 85mm(D)
- Pressure gauge: Integrated 40mm dial (0-1.0 MPa scale)
- Adjustment knob: Lockable rotary type with ±2% set pressure accuracy
- Filter rating: 5μm (built-in)
- Vibration resistance: ≤4.9 m/s²
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating loads. The balanced poppet structure minimizes pressure creep, while the T-handle adjustment allows precise control even with gloved hands. Includes a bleed valve for safe depressurization.
- Pneumatic actuator pressure stabilization
- Packaging machine clamping force control
- CNC machine tool air circuit regulation
- Semiconductor manufacturing equipment
- Automated assembly line pressure zoning
Installation protocol:
Mount vertically with arrow direction matching airflow. Install downstream filter (≤0.3μm)
when used with precision instruments. Lubricate quarterly with ISO VG32 turbine oil
if air line lacks lubricator.
| Property | Property Value |
|---|---|
| sku | GAR20008SJNK |
| Port Size | PT1/4 |
