Airtac GC FRL Unit GC20006C1K
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Triple Unit GC20006C1K Full Specifications
- Model: GC20006C1K (Compact Combination Unit)
- Configuration: Filter + Regulator + Lubricator (FRL)
- Port size: PT1/4 (G1/4 equivalent)
- Max operating pressure: 1.0 MPa
- Flow capacity: 2000 L/min (ANR)
- Filter rating: 5 μm (replaceable sintered element)
- Regulator range: 0.05–0.85 MPa
- Lubricator capacity: 180 cm³ (oil cup)
- Drip rate adjustment: 0–60 drops/min
- Body material: Aluminum alloy (anodized)
- Seal material: NBR + Fluororubber hybrid
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.25 kg (with oil)
- Dimensions: 195mm(W) × 145mm(H) × 85mm(D)
- Mounting: Panel bracket or rail mount
Integrated FRL unit combining 40μm pre-filter, precision pressure regulation, and adjustable lubrication. Features transparent bowls with anti-static coating, manual bypass for emergency operation, and corrosion-resistant internals. Includes pressure gauge port (R1/8) and auto-drain function (optional).
- Pneumatic production line header systems
- CNC machine tool air preparation
- Packaging machinery main air supply
- Automated assembly line tooling stations
- Industrial robot end-effector control
Maintenance protocol:
Drain condensate daily via bottom lever. Replace filter element every 2,000 hrs.
Use ISO VG32 turbine oil in lubricator. Install upstream shut-off valve for servicing.
- Install filter first in airflow direction (→ marking)
- Position regulator vertically (±15° tolerance)
- Set lubricator 500mm downstream from actuators
- Purge system for 30 sec before initial operation
| Property | Property Value |
|---|---|
| sku | GC20006C1K |
| Port Size | PT1/8 |
