Airtac GC FRL Unit GC20006C3K
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006C3K Specifications
- Model: GC20006C3K
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa
- Maximum pressure: 1.0 MPa
- Filtration rating: 5 μm (replaceable element)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.0 MPa scale)
- Adjustment knob: Lockable rotary control with ±2% accuracy
- Flow capacity: 2000 L/min (ANR)
- Oil capacity: 20 mL (transparent bowl)
- Temperature range: -5℃ to 60℃
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR (nitrile rubber)
- Weight: 820 g ±5%
- Dimensions: 148mm(H) × 72mm(W) × 72mm(D)
Modular FRL unit combining precision air preparation functions with tool-free bowl removal. Features a dual-chamber filter design with automatic drainage and anti-rotation bracket. The integrated bypass mechanism maintains airflow during element replacement. Requires 7-10 bar compressed air input.
- Pneumatic assembly line main air preparation
- CNC machine tool pneumatic systems
- Industrial robot end-effector control
- Packaging machinery air circuit protection
- Automotive painting system air conditioning
Installation note:
Mount vertically with arrow aligned to airflow direction. Maintain 50mm
clearance below bowl for drainage access. Lubricator should be filled
with ISO VG32 turbine oil. Replace filter element every 2,000 operational hours.
| Property | Property Value |
|---|---|
| sku | GC20006C3K |
| Port Size | PT1/8 |
